Throughput up to 60 samples/hour with whole blood mode
10.4 inch color display screen with touch panel
Minimum volume 9μL whole blood
Large storage capacity, 300,000 results
Principles | Impedance method (WBC, RBC, PLT) and cyanide free colorimetric method (HGB) |
Parameters | 24 parameters: (WBC, Lym#, Mid#, Gran#, Lym%, Mid%, Gran%, RBC, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PDW-CV, PDW-SD, PCT, HGB, PLCC, PLCR, NLR, PLR ), 3 histograms |
| Reagent | 1 diluent and 1 lyse reagent |
Performance | Parameter Linearity Range Repeatability Carryover WBC 0-300*10^9/L 2%(7-15*10^9/L) 0.5% RBC 0-8*10^12/L 1.5%(3.5-6.5*10^12/L) 0.5% PLT 0-4000*10^9/L 4%(150-500*10^9/L) 1% HGB 0-280g/L 1.5%(100-180g/L ) 0.5% |
Sample Volume | Minimum volume 9μL whole blood |
Throughput | 60 samples per hour |
| Display | 10.4 inch TFT Touch Screen |
Mul | English, Option: Chinese, Portuguese, Spanish, Russian, French |
| Data Storage Capacity | Up to 300,000 results including numeric and graphic |
Communication | LAN port supports HL7 protocol |
| Interface | 4 USB ports,1 LAN port |
| Printout | Built-in thermal printer； Support directly connected with more than 15 types USB HP printers； Support different language when leaving the factory； Multiple built-in report templates available； |
Opera | Temperature: 10 ℃-35 ℃ Humidity: 20%-85% |
| Power requirement | 100-240VAC, 50/60Hz, 150VA |
| Dimension | 420mm(L)*295mm(W)*430mm(H) |
| Net Weight | ≤28kg |
